The briquette dryer is an important piece of equipment for the production of high-quality briquettes. The primary function of the dryer is to remove excess moisture from the briquettes, ensuring that they are fully cured and ready for use. The dryer is typically installed after the briquette press, and the briquettes are fed into the drying chamber through a conveyor belt. Once inside, the briquettes are subjected to a continuous flow of hot air, which is produced by a gas-fired burner or an electric heater or biomass burner or coal burner and ect.
One of the key features of a briquette dryer is its ability to withstand harsh working environments. The dryer is typically constructed from high-strength materials, such as stainless steel or carbon steel, that can withstand high temperatures and resist corrosion. Additionally, the dryer is often equipped with heavy-duty bearings and other components that are designed to handle the constant movement of the drying conveyor belt.
Another important feature of a briquette dryer is its ability to produce a high-quality, evenly-dried product. To achieve this, the dryer must be equipped with precise temperature and humidity controls that ensure that the briquettes are dried uniformly. These controls also allow operators to tailor the drying process to meet specific production requirements, such as drying time and temperature.
1. The difference between chain plate dryer and mesh belt dryer
Both chain plate dryer and mesh belt dryer belong to batch and continuous production drying equipment. The mesh belt dryer mainly transports the briquettes directly to the flat conveyor through the conveyor. The scraper at the upper end of the conveyor evenly distributes the briquettes on the dryer to improve the air permeability of the briquettes and achieve the drying effect. The chain dryer is a drying equipment that uses steel chain plates as conveyor belts to carry materials for continuous drying. One layer can be used as two layers, which fully utilizes the heat and has a high drying efficiency. It has a good drying effect for customers who need to dry the briquette to a lower level of water content.
Compared with the mesh belt dryer, the chain plate dryer has the following advantages:
1. The design of the chain palte dryer is reasonable, which prolongs the residence time of the material and the feeding speed, which can make the material obtain a good drying effect.
2. The equipment configuration is flexible. It can be used with the equipment flip dryer configured with the mesh belt dryer, which is an upgraded version of the mesh belt dryer.
3. Most of the air in the chain plate dryer is recycled, which is highly energy-saving.
4. The unique air distribution device of the chain plate dryer makes the distribution of hot air more uniform and ensures the consistency of product quality.
5. Compared with the mesh belt dryer, the chain plate dryer greatly reduces maintenance costs and labor costs.
2. Is the dryer safety ?
Yes, our dryer is safety and high efficiency compared with traditional mesh belt dryers and vertical dryers. We make some explanation for you:
1st, For common materials, our design working temperature is 80-120℃, can up to 150℃.we design idea is low temperature and high air volume, it’s safe and low fuel.
2nd,we install temperature sensor and high temperature warning light,you can see the temperature inside the dryer and control it.
3rd,fan overload protection and current overload protection included.
3. Pls confirm if you can provide a detailed layout for the equipment’s installation & the necessary civil work.
Yes, we can offer detailed layout for the equipment’s installation & the necessary civil work.
4. The drying tunnel is it separated by segments that would be assembled later? Or is it a single and indivisible body? It is to know how we can get it to the place where we think it should go. Pls confirm
Yes,The dryer is built by segments section, every center section size (LWH) 2*2.25*2.25 meter , dryer head and end 1.3/1.4*2.25*2.25 meters， which will be load into container easy and connection & fixed at site by workers. Weight section weight is around 2-2.5tons;
5. How to install and test dryer? Do you need professional technicians to operate?
Each customized dryer has detailed drawings and operating parameters designed by professional engineers, and production and installation will be completed according to the drawings and parameters. At the same time, our company also provides 3D pictures for installation reference; detailed drawings will be sent to customers along with the equipment.
After the installation and commissioning of the equipment is completed, professional operators are not required to operate and maintain the equipment, and ordinary skilled workers can perform equipment operation and maintenance (except circuit maintenance).
